SECAM has been supporting you for over 50 years in the design and industrialisation of inserts for plastics, light alloys and wood, with more than 300 references available from stock.
30° Thread self-drilling screw
High resistance to vibrations
Reduced stresses on the boss
Increased material flow
Increased holding force
Reduced risk of shearing
Reduced installation cycle time
30° thread
Thread
root draft
Pitch optimisation
Dimensions
Manufacturing' programme
For countersunk heads, add 2 mm to the length
Valeurs en mm
Code Reading
Installation guide
Boss Design
Assembly recommendations
The thread is formed by heating the plastic. We recommend using an electric or
pneumatic screwdriver.
A speed of between 500 and 600 r.p.m. is required in thermoplastics and
between 300 and 1000 r.p.m. in light alloys
Excessive speed may damage the material and destroy the thread.
Screw drives
Screw drives
Advantages of the torx drive
- Increases the torque transmission
- Limits the tool pressure on the screw
- No slipping of the tool in the screw drive
- Reduces wear on the screw drive
and the screwdriver - Suitable for all types of screw
Hexagonal socket
Cruciforme Z
Pozidrive
Cruciforme H
Phillips
